c餤媩 / English Version
2000.11. MIL technology Co.,Ltd. was established in 1981.
2000. Planned new factory by shareholders
2001. Added D/FBTest equipments
2002.05. Expended process capacity to Layers 4.6.8
2004.02. Expended process capactity to layers 12
2006.06. Expended to layers 20 ABoard thickness 0.008~0.137, Line width/space 4/4mil with RoHs compliant
2007. Via in Pad
Our Mission
It is our clear intention to expand our global presence and market leadership. As we expand our worldwide presence, we will continue to extend our capabilities in the development, marketing and sale of our leading edge applications.
  MIL Technology Co., Ltd was established in 2000.Since conception we have been in the field of Printed Circuit Boards.We keep improving our products and the technology used. Our staff is highly skilled and we adopt strict quality control standards.
Our products are used extensively in many industries including:
* Computer products
* Consumer goods
* Medical equipment
* Electric machinery
* Automobile components
* Telecommunications
We are committed to provide outstanding product quality at a competitive price and accurate delivery.

Max. board size 21*24
Board thickness 0.015~0.138
Layers 1~20Layers
Copper cladding 0.5~3oz
Aspect ratio 7:1
Impedance control 50ohm+/-10%
Thickness tolerance +/-0.005
Min. hole size 0.008
True position +/-0.003
Min. Line width/space for Outer and Inner 3/3milB4/4mil
Tending 0.010~0.0256
The plating thickness of G/F 2~30u
The plating thickness of Electronless gold 2~5u
Silkscreen width 0.030
CNC- Router / Punch +/-0.005 / +/-0.003
E-Test condition 200V 5M 50ohm
CAM system Genesis 2000
Surface treatment OSP, HASL, Immersion Gold/Tin/Ag, Carbon Print, Peelable Mask, Lead-Free HASL
Base material FR-4, CEM-3, Hi-TG 150/170
